Settings Reference
The Settings panel configures the services and defaults the rest of the app depends on. Settings are stored in the database (not browser storage), so they apply to every session and survive restarts. Sensitive values are encrypted at rest.
Endpoints Tab
Where labeling LLMs live.
| Setting | Purpose |
|---|---|
| OpenAI-compatible endpoint | Base URL of any OpenAI-compatible server (vLLM, Ollama's OpenAI shim, miLLM, LM Studio…) used for labeling |
| OpenAI-compatible model | Model name to request from that endpoint |
| Ollama / LLM Service URL | Base URL for a local LLM service. Overrides the server's environment variable. |
The Fetch Models button queries the configured endpoint's /models list, so you can pick from what the server actually serves instead of typing model names blind.
API Keys Tab
| Key | Used for |
|---|---|
OpenAI API Key (sk-proj-…) | Bulk + enhanced labeling against api.openai.com |
HuggingFace Token (hf_…) | Gated model/dataset downloads, SAE uploads to the Hub |
Keys are encrypted at rest with AES-256-GCM and never displayed in full after saving — the UI shows a masked placeholder. Re-entering a key replaces the stored ciphertext.
Labeling Tab
Defaults for the labeling pipelines (individual jobs can still override them):
| Setting | Default | Description |
|---|---|---|
| Default Batch Size | 10 | Features per LLM request in bulk labeling |
| Default Max Examples per Feature | 25 | Activation examples shown to the LLM per feature |
| Labeling Method (enhanced) | OpenAI-compatible | Backend for enhanced labeling: openai (api.openai.com) or openai_compatible (your endpoint) |
| OpenAI Model (enhanced) | gpt-4o-mini | Model for enhanced labeling when method = OpenAI. Fetch Models lists your account's available models. |
| Max Parallel Workers (Pass 1) | 8 | Concurrency for enhanced labeling's per-example summarization pass |
Reasoning-class OpenAI models (gpt-5, o1/o3/o4 families) are auto-detected — miStudio switches to max_completion_tokens and strips <think> blocks from responses, so they work in labeling without special configuration.
Display Tab
Display preferences (theme, sidebar collapse) are controlled from the header and stored locally in your browser — they don't sync across devices.
PIN Protection
Because Settings holds API keys and arms irreversible checkpoint deletion, two tabs can be locked behind a PIN:
- Set a PIN in the API Keys tab. From then on, opening API Keys or Storage prompts for it once per session.
- The PIN is stored as a PBKDF2-SHA256 hash — it is not recoverable, only resettable.
The PIN is a UI affordance, not authentication.
- It gates two tabs, not the panel. Endpoints, Labeling and Display open without it, and the tab bar always renders. This page previously said "the panel can be locked", which is not what the code does (MIS-E2E-160) — and until that was fixed the Storage tab, which arms irreversible checkpoint deletion, was the one destructive surface left ungated.
- It does not gate the API. Every setting reachable through the UI is reachable over HTTP without it. miStudio has no per-user authentication by design — see PADR IDL-47 for the posture, its boundary and what invalidates it.
- Treat it as "stop me clicking the wrong thing", never as access control. If you need real access control, the network boundary is where it lives.
Forgot your PIN? Set the environment variable on the backend and restart:
MISTUDIO_BYPASS_PIN=true
The Settings panel opens without a PIN and shows a persistent warning banner. Reset your PIN in the API Keys tab, then remove the flag and restart — bypass mode is for recovery, not day-to-day use.
